Maintenance
500 HOUR MAIN SERVICE
CAUTION: If you need to open the bonnet, follow the procedure indicated under “How to open the bonnet”.
WARNING: Always use specific personal safety devices for each operation.
WARNING: Maintenance operations must be carried out with the engine off. Check that the gear and the parking
brake are both engaged and that the ignition key has been removed.
WARNING: Beware of burns caused by hot tractor and engine parts. [4.1.n]
Change front PTO oil and clean the oil filter
OPERATION1
Putthetractoronlevelground.
Removethehose(1)andallowtheoiltodrainintoasuit-
ablecontainer.
Forbestresultsdraintheoilafteroperationwhentheoil
iswarm.Oncetheoilhascompletelydrainedre-attach
thehose.
IMPORTANT: Dispose of oil in accordance with local
regulations. DO NOT DRAIN THE OIL ON THE GROUND
OR INTO A DRAIN. Be responsible for the environment.
OPERATION2
Removethecirclip(2)andloosenthebolt(3).
OPERATION3
Removethepumpcover(4).Removetheoilfilter(5)from
thepumpunitandcleanthefilter.
OPERATION4
Installthecleanoilfilter,thepumpcover(4)andtighten
thebolt(3).Installthecirclip(2).
OPERATION5
Addtherecommendedoiltypethroughthefill/levelplug
hole(6)untiltheoilislevelwiththebottomedgeofthe
hole.
Waitapproximately5minutes.Checktheoillevelagain
andaddoilasnecessary.Installthefill/levelplug.
