11.3 Brake options
Figure 11.a - Braked Axle
Hydraulic brakes 
This system utilises one hose for connection to the tractors hydraulic brake coupling.
This is the most common system on the machine.
Air brakes 
This system utilises two air brake couplings and the use of which may be mandatory in
certain countries. Always obey local road regulations!
11.4 Tyre options
11.5 Side tip option

The side tip option is used for knocking the bale onto it’s side and is very useful for
course ground with strong stubble (which may have a tendency to puncture the film),
as it allows the bale to land on it’s edge, which has a much higher degree of film
coverage. It is also very useful on hilly/sloping ground as it can prevent bales from
rolling, when they land on their side.The side tip is attached to the rear wrapping cradle.
Type Details Part No
A 
Vredestein 560/60 R22.5 (Flo-Pro) CWH00053
B 
BKT 560/60 R22.5 CWH00068
C 
Vredestein 650/50 R22.5 (Flo-Pro) CWH00054
