4.2 - Velocity check
In order to execute the velocity check the treadmill must obviously be under tension, and should the
hood be open, one must be extremely careful. To apply tension with the hood open, the following
steps should be followed in the following order:
1) block the security switch in the closed position
2) connect the power plug
3) switch ON the main switch
WARNING:
From this moment on, the machine is under tension, and you are advised to be extremely careful
in order to avoid accidental contact with the parts under tension
The velocity check is performed using the PC’s software to send a movement command to the
treadmill. If the belt moves in the correct way after having received the command, the velocity
check is OK; otherwise it is NOT OK.
After executing the check, since one has to continue working on the treadmill with the cover open,
you are advised to remove the tension from the treadmill, using the following steps:
1) Switch OFF the main switch
2) unplug the power plug
4.3 - Inverter check
To execute the inverter check, you must work with the hood open and the machine under tension.
To apply tension, following the steps in the order given:
1) block the security switch in the closed position
2) connect the power plug
3) switch ON the main switch
WARNING:
From this moment on, the machine is under tension, and you are advised to be extremely careful
in order to avoid accidental contact with the parts under tension
The test is simply to control if the inverter display is lit and that the light of the "STOP" button
flashes (Fig. 20).
If the display is lit, but not flashes, switch OFF the main switch, wait 30 seconds and restart.
If the display is illuminated and the light of the "STOP" button flashes the test is OK, otherwise it
is not OK.
