Medisoft 870 S - 8 - Setting RS232 Communication in MPH or Km;h

Service Manual 800 series Rev. 1/01.07.2019
55
Medisoft RAM Italia S.r.l. - All rights reserved
8 - Setting RS232 command execution in MPH or Km / h
This procedure is performed on the control board, allowing the correct execution of the rate
parameter, in the measuring unit actually transmitted by the stress test system.
It 'still required to verify practice during installation, as requested in paragraph 3.6 of the manual.
Mounting the bridge at the pin "JP1", the treadmill is running properly configured serial commands
in
km / h
(Fig. 51)
Fig. 51
Excluding the bridge at the pin "JP1", the treadmill is running correctly configured in the serial
commands
MPH
(Fig. 52)
Fig. 52
