6.19 - Restoring the gliding subsystem
Essential tools:
• Cross-head screwdriver
• Flat blade screwdriver
• 5,5, 10 and 13mm wrench
• 3, 4, 6, 8mm allen wrench
Apply the extension spar previously removed.
Insert the rear roller into the running belt, supporting the shaft in its position on the frame, insert
the protective plate of the roller and restore without blocking the screws.
Restore the two brackets previously removed from the end of treadmill and fix with 10mm wrench
Apply the screws with your head 13mm, but without to tension the running belt.
Insert the front roller into the running belt, supporting the shaft in its position on the frame.
Fit a new transmission belt on the front roller pulley, then apply the screws onto the front roll
without even tighten them.
Fit the transmission belt also in the motor pulley.
Apply the handlebar and the plastic elbow removed earlier.
Position the belt tensioner support on motor box and apply the screws without tightening them
yet.
Tighten the belt tensioner bolt to tension the belt temporarily.
Apply on the surface of running belt two pieces of paper tape at a precise distance of 1000mm.
Before everything, put in the middle the running belt on the wooden bottom, then use the 13 mm
wrench, alternately tighten the bolts tend tape at the feet of the treadmill.
The tension of the tape must be verified by the measure of the same between the two applied
references, which should be 7 mm (the original measure 1000, the final measure 1007).
At this point it is necessary to put in rotate the running belt to adjust the trim of the same
horizontal.
