Reposition the drive belt in its place, working first on the flywheel pulley and then on the front
roller pulley.
Fasten the screws at the base of the motor to lock it into position.
Re-insert the support roller belt tensioner, but don’t tighten them yet.
Tension the belt with the adjusting screw, then tighten the screws that secure the support.
Reconnect the wire of the cooling fan.
Reconnect the power wire to the new motor, like the old one.
Screw the cable blocker, reposition the clamp cover in its place and close it by fastening the four
screws.
5 - Diagnosis of power subsystem
This procedure, whose flow chart is described in the next paragraph, considers the possibility that
the treadmill does not turn on. This condition involves both the lack of power to the treadmill (in
this case the warning light located on the main switch is off) and the incorrect distribution of power
to the treadmill components (in which case the inverter display is off).
The following is a list of possible malfunctions of the power subsystem
1. Power cable
2. Main switch
3. Warning light
4. Connecting cable between components
5. Filter board
6. Contactor
7. Safety switch
8. Cable or button, emergency stop switches
