Meggitt vibro-meter VM600 Quick Start Manual

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600
Mk2
machinery protection system (MPS)
2-9
MPC4
Mk2
machinery protection and condition monitoring module
OVERVIEW OF VM600
Mk2
MACHINERY PROTECTION SYSTEM (MPS) HARDWARE
(e)
Configuration as per (b).
Danger alarms for CH1 and CH2
(dual-channel processing)
and CH3.
CH3 is the first-out alarm.
System unlocked
Figure 2-2 (continued): MPC4
Mk2
LED activity for typical VM600
Mk2
MPS situations
(d)
Configuration as per (b).
Alarm bypass (AB) active.
System unlocked.
(f)
Configuration as per (b).
Fail safe: system in safe state.
System unlocked.
Note:
LED
blinking
quickly.
Note:
LEDs
blinking
slowly.
Note:
LED
blinking
quickly.
