Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600
Mk2
machinery protection system (MPS)
2-27
RLC16
Mk2
relay module
OVERVIEW OF VM600
Mk2
MACHINERY PROTECTION SYSTEM (MPS) HARDWARE
Table 2-9: RLC16
Mk2
module J3 connector pinouts
RLC16
Mk2
J3 connector: RELAYS
Label Pin
Name /
function
Direction Definition
11
1 RLY11_COM O Relay 11 common (COM) contact
12
2 RLY12_NC O Relay 12 normally closed (NC) contact
3 RLY12_NO O Relay 12 normally open (NO) contact
4 RLY12_COM O Relay 12 common (COM) contact
13
5 RLY13_NC O Relay 13 normally closed (NC) contact
6 RLY13_NO O Relay 13 normally open (NO) contact
7 RLY13_COM O Relay 13 common (COM) contact
14
8 RLY14_NC O Relay 14 normally closed (NC) contact
9 RLY14_NO O Relay 14 normally open (NO) contact
10 RLY14_COM O Relay 14 common (COM) contact
15
11 RLY15_NC O Relay 15 normally closed (NC) contact
12 RLY15_NO O Relay 15 normally open (NO) contact
13 RLY15_COM O Relay 15 common (COM) contact
16
14 RLY16_NC O Relay 16 normally closed (NC) contact
15 RLY16_NO O Relay 16 normally open (NO) contact
16 RLY16_COM O Relay 16 common (COM) contact
Notes
COM = common, DSI = discrete signal interface, G = ground, HI = high, I = input, LO = low, NC = normally closed, NO = normally open,
O = output, PG = protective ground, R = return, S = shield, SHIELD = shield / protective ground,
SPS = sensor/measurement chain power supply
