Megmeet MV600 Series User Manual

189
P10.05 is used for selecting the analog and pulse curve.
Where the value range of P10.07, P10.09, P10.11, P10.13, P10.15, P10.17, P10.19 and P10.21 is as
follows: Take as the frequency reference, its value range is 0.0~100.0
％
Fmax; 0.0~300.0
％
Te for the
torque and 0.0~100.0
％
Φe for the magnetic flux.
For example, the demand analysis is as follows:
1
） Setting the set frequency with the pulse signal input by the terminal;
2
） Input signal 1kHz~20kHz;
3
） The 1kHz, 8kHz, 12kHz and 20kHz input signal shall correspond to the set frequency of 50Hz,
10Hz, 40Hz and 5Hz respectively.
Based on the above requirements, the parameter settings are as below:
P02.04=4, adopting the terminal PULSE reference as the main frequency reference channel.
1
） P09.07=12, input the pulse signal from X8 terminal;
2
） P10.05=2000, select the curve 1;
3
） P09.11=20.0kHz, set the maximum pulse input frequency as 20kHz;
4
） P10.14=20÷20×100％=100.0％, set the percentage of the maximum reference of curve 1 (20kHz)
relative to 20kHz (P09.11);
5
） P10.15=5.00Hz÷P02.15 x100％, set the corresponding set frequency percentage of the maximum
reference (20kHz pulse signal);
6
） P10.16=12÷20×100％=60.0％, set the percentage of the inflection point 2 of the curve 1 reference
(12kHz) relative to 20kHz (P09.11);
7
） P10.17=40.00Hz÷P02.15 x100％, set the corresponding set frequency percentage of the inflection
point 2 of the curve 1 reference (12kHz pulse signal);
Actual value corresponding to the minimum reference of curve 1
0.0~300.0%
(
0.0%
)
P10.21
Minimum reference of curve 1 0.0%~P10.18
(
0.0%
)
P10.20
Actual value corresponds to the inflection point 1 of the curve 1
0.0~300.0%
(
0.0%
)
P10.19
Inflection
p
oint 1 of the curve 1 reference P10.20~P10.16
(
0.0%
)
P10.18
Actual value corresponds to the inflection point 2 of the curve 1
0.0~300.0%
(
100.0%
)
P10.17
Inflection
p
oint 2 of the curve 1 reference P10.18~P10.14
(
100.0%
)
P10.16
Actual value corresponding to the maximum reference of curve 1
0.0~300.0%
(
100.0%
)
P10.15
Maximum reference of curve 1 P10.16~100.0%
(
100.0%
)
P10.14
Actual value corresponding to the minimum reference of line 2
0.0~300.0%
(
0.0%
)
P10.13
Minimum reference of line 2 0.0~P10.10
(
0.0%
)
P10.12
Actual value corresponding to the maximum reference of line 2
0.0~300.0%
(
100.0%
)
P10.11
Maximum reference of line 2 P10.12~100.0%
(
100.0%
)
P10.10
Actual value corresponding to the minimum reference of line 1
0.0~300.0%
(
0.0%
)
P10.09
Minimum reference of line 1 0.0%~P10.06
(
0.0%
)
P10.08
Actual value corresponding to the maximum reference of line 1
0.0~300.0%
(
100.0%
)
P10.07
Maximum reference of line 1 P10.08~100.0%
(
100.0%
)
P10.06
