Megmeet MV600 Series User Manual

191
Table 6-14 Analog output terminal indication
Item Function Indication range
0 Output frequency 0~Maximum output frequency
1 Set frequency 0~Maximum output frequency
2
Set frequency (after acceleration/
deceleration)
0~Maximum output frequency
3
Rotating speed of motor (V/F
control disabled)
0~Maximum rotating speed
4 Output current 0 ~ 200% of the rated current of the drive
5 Output current 0 ~ 200% of the rated current of the motor
6 Output torque 0 ~ 300% of the rated torque of the motor
7 Output torque current 0 ~ 300% of the rated torque of the motor
8 Output voltage 0 ~ 120% of the rated voltage of the drive
9 Bus voltage 0~800V
10 AI1 0~Maximum analog input
11 AI2 0~Maximum analog input
12 AI3 0~Maximum analog input
13 Output power 0 ~ 200% of the rated power of the motor
14 Percentage of host device 0~4095
15 Torque limit value 1 0 ~ 300% of the rated torque of the motor
16 Torque limit value 2 0 ~ 300% of the rated torque of the motor
17 Torque offset 0 ~ 300% of the rated torque of the motor
18 Torque command 0 ~ 300% of the rated torque of the motor
19 Flux command 0 ~ 100% of the rated flux of the motor
20 Reserved
21 Output torque (bipolar) -300 ~ 300% of the rated torque of the motor
22 Output torque current (bipolar) -300 ~ 300% of the rated torque of the motor
23 Torque offset (bipolar) -300 ~ 300% of the rated torque of the motor
24 Motor rotating speed (bipolar)
Negative maximum output frequency ~
maximum output frequency
25 Reserved Reserved
26 Percentage of bus card 0~4095
 Note
1. When the function corresponding to the AO output is unipolar, the indication value corresponding to the
minimum output has the minimum absolute value, while the indication value corresponding to the maximum
output has the maximum absolute value. When the function is bipolar, the indication value corresponding to
the minimum output is the smallest, while the indication value corresponding to the maximum output is the
biggest.
2. When the AO output is current, it is suggested that the external equivalent resistance not exceed 400ohm.
