When the drive is in stop, the operation panel displays the stop status parameter, as shown in Fig.4-2a.
The lower unit LEDs show the parameter units, while the upper QUICK and BASIC combination indicates
the current menu mode.
When the verification menu is selected, only the function codes whose parameter value is different from
the leave-factory value will be displayed. You can press the
∨ or ∧ key to browse all the function
codes whose parameter set value is different from the leave-factory value, and check which parameters
have been changed.
Different stop status parameters can be cyclically displayed by pressing the
key (defined by function
code P16.02).
2. Run parameter display status
When the drive receives the valid running command, it will enter the run state, the operation panel will
display the running status parameter, and RUN LED on the panel will be on, and ON/OFF of the FWD
and REV LEDs depend on the current running direction. As shown in Fig.4-2b, the lower unit LEDs
display the parameter units.
When the key is pressed, the running status parameters will be cyclically displayed. The running
status parameters that can be viewed are defined by the function codes P16.00 and P16.01.
3. Alarm display status
When the drive detects abnormal conditions during running but it can still continue to run, it will enter the
alarm display status. The upper Alarm LED will be on, and the corresponding alarm code will be
displayed on the operation panel, as shown in Fig. 4-2c.
When the key is pressed, the running status parameters and alarm code will be cyclically displayed.
When there are several alarms, the operation panel will cyclically display each alarm code at preset
intervals.
To continue running, you can disable the fault alarm and stop by setting the protection action P97.00 and
P97.01. The alarm will disappear during running, and the system enters the normal running parameter
display status. If the alarm still exists before stop, the corresponding fault code will be automatically
displayed upon stop.
The alarm status can be treated as a special fault status. Same as the fault status, you cannot adjust the
frequency parameters through the
∨or ∧ key in the alarm state. You must switch to the run parameter
display status by pressing the
key before you can use the ∨or ∧ key to adjust the set frequency
parameters.
