Megmeet MV600 Series User Manual

80
P05.01
Speed loop
low-speed
integral time
（ASR1-I）
Speed loop
low-speed
integral time
0.000~10.000S 0.001s 0.200s √ √ ○
P05.02
ASR1
output filter
ASR1 output
filter
0~8 (corresponds to 0~2^8/8ms) 1 0 × √ ○
P05.03
ASR
switching
frequency 1
ASR
switching
frequency 1
0.0％~50.0%
0.1
10.0％
× √ ○
P05.04
Speed loop
high-speed
proportional
gain
（ASR2-P）
Speed loop
high-speed
proportional
gain
0.1~200.0 0.1 10.0 √ √ ○
P05.05
Speed loop
high-speed
integral time
(ASR2-I)
Speed loop
high-speed
integral time
0.000~10.000S 0.001s 0.600s √ √ ○
P05.06
ASR2
output filter
ASR2 output
filter
0~8 (corresponds to 0~2^8/10ms) 1 0 × √ ○
P05.07
ASR
switching
frequency 2
ASR
switching
frequency 2
0.0％~100.0%
0.1
20.0％
× √ ○
P05.08
Proportional
gain of
special
speed
section for
speed loop
(ASR3-P)
Proportional
gain of
special
speed
section for
speed loop
0.1~200.0 0.1 20.0
×
√ ○
P05.09
Integral time
of special
speed
section for
speed loop
（ASR3-I）
Integral time
of special
speed
section for
speed loop
0.000~10.000s 0.001s 0.200s × √ ○
P05.10
ASR
switching
frequency 3
ASR
switching
frequency 3
0.0％~100.0%
0.1
80.0％
× √ ○
P05.11
Differential
gain
enabling
Differential
gain enabling
0: Disable
1: Enable
1 0 × √ ×
P05.12
ASR
differential
gain
ASR
differential
gain
0.00~10.00 0.01 0.00 × √ ○
P05.13
Electric
torque limit
channel
Electric
torque limit
channel
0: Electric torque limit value
1: AI reference
1 0 × √ ×
