Chapter 3 – Initial Commissioning
22
Electrical connection
Provide the following electrical connections for the steam sterilizer:

Electric circuit with 220-240 V (max. voltage range 207 - 253 V) and
50/60 Hz (MELAquick 12+) and 50 Hz (MELAquick 12+ p, see name
plate)

10 A separate fuse protection – at least Automat Type B

Protection from leakage current 30 mA
Danger of injury
■ The connections for electrical provision and water supply and
discharge must be set-up by trained personnel.
Non-observance could lead to a short-
circuit and/or fire and/or water
damage and/or electrical shock. This could result in serious injury.
Observe the following precautionary measures when handling the
mains cable and power plug:
Danger of injury
■ Never splice or change the mains cable.
■ Never bend or twist the mains cable.
■ Never unplug by pulling on the power cable (socket and steam
sterilizer). Always take a grip on the plug.
■ Never place any heavy objects on the mains cable.
■ Never run the mains cable over places where it could be squeezed
(e.g. doors or windows).
■ Never lead the cable along a source of heat.
■ Do not use any nails, staples or similar objects to fixate a cable.
■ If the mains cable or the power plug is damaged, turn off the steam
sterilizer. Mains cables or power plugs may only be replaced by →
authorised persons.
If these points are not observed, the cable or plug can be damaged
and/or a fire or electrical shock might occur. This could result in
serious injury.
Connecting the mains cable
Plug the mains plug into the socket and the IEC plug into the mains
connector (see Fig. 1/(10)).
Attention
■ The IEC plug on the steam sterilizer or the mains socket must be
freely accessible after installation so that the steam sterilizer can be
taken from the electricity supply at any time.
Preconditions for commissioning
The following prerequisites must be satisfied for initial start-up:

The feed water supply must be connected and filled with fresh feed
water of the appropriate quality and/or a water treatment unit must be
connected as alternative.

The waste water container must be connected.

The compressed air line must be connected.
 The power supply of the steam sterilizer must be assured.
Record of installation and setting
up
PLEASE NOTE
As docu
mentation of proper setting up, installation and commissioning as
well as for your warranty claim, the record of installation
and set up must
be filled out by the person responsible and a copy sent to MELAG.
