Chapter 5 – Logging
41
---------------------------------------
MELAG MELAquick 12+
---------------------------------------
Header
Program : Universal-Program S
134°C wrapped
Date : 13.03.2015
Time of day : 12:16:14 (Start)
Batch number: 2
SN : 201512+p1017
---------------------------------------
Started program
Current date
Time at program start
Daily batch number
Serial number
Preheating 133.5 °C
AIN6: Conductivity 12 µS/cm
Preheating temperature
→conductivity of the →feed water
Preheating 133.5 °C
AIN6: Conductivity 12 µS/cm
Program step Press. Temp. Time
bar °C min
Start 0.02 127.6 00:00
1.Fractionation
Steam entry 1.75 128.6 00:54
Press. release 0.19 127.4 01:00
2.Fractionation
Steam entry 1.72 129.7 01:27
Press. release 0.22 118.0 01:35
3.Fractionation
Steam entry 1.71 129.8 02:04
Press. release 0.25 108.7 02:14
4.Fractionation
Steam entry 1.71 129.8 02:45
Press. release 0.25 108.7 02:58
5.Fractionation
Steam entry 1.72 130.1 03:33
Press. release 0.24 108.2 03:49
6.Fractionation
Steam entry 1.72 130.1 04:25
Press. release 0.23 107.3 04:42
7.Fractionation
Steam entry 1.71 130.0 05:20
Press. release 0.25 108.2 05:36
8.Fractionation
Steam entry 1.72 130.0 06:13
Press. release 0.24 108.8 06:30
9.Fractionation
Steam entry 1.71 130.0 07:08
Press. release 0.23 108.5 07:26
Heat up 2.04 134.3 08:26
Steriliz.begin. 2.04 134.3 08:26
Steriliz.end 2.18 136.1 11:56
Press. release 0.16 108.7 12:10
Flow drying
Drying begin. 0.16 108.7 12:10
Drying flow 0.12 103.1 12:16
Drying pumping 1.20 107.1 12:29
Drying end 1.21 123.1 20:06
End 0.02 123.0 20:11
Program step values
Program sequence phases with the accompanying values
for pressure, temperature and time (relative to the
program start)
------------------------------------------
Summary
PROGRAM PROPERLY EXECUTED!
Control message
Temperature : 136.0 +0.3 /-0.2 °C
Pressure : 2.18 +0.02/-0.02 bar
Sterilizate time: 3 min 30 s
Time of day : 12:36:25 (End)
---------------------------------------
Mean sterilization temperature with max. deviations
Mean sterilization pressure with max. deviations
Sterilization time maintained
Time at the end of the program
58 20150101 5.15 5.05
Information with total-cycle counter, factory serial number
and device software version no.
Fig. 12: Example of a program log for a successful finished Universal-Program S
