90-830234R3 DECEMBER 1997 FUEL SYSTEM - 3B-9
Carburetor (WME–59/60/61/62/75/76/77/78/82/83)
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
11 3 GASKET–cover plate
12 3 SPRING–idle needle
13 2 IDLE NEEDLE
14 2 THROTTLE LEVER (TOP/BOTTOM)
15 2 THROTTLE SHAFT (TOP/BOTTOM)
16 3 SPRING–throttle return
17 3 GASKET–nozzle well
18 3 GASKET–fuel bowl
19 3 INLET NEEDLE VALVE
20 3 FLOAT
1 FUEL BOWL (UPPER)(WME-60)
21 2 FUEL BOWL (CENTER/LOWER)(WME–60)
3 FUEL BOWL (WME–59/61/62/75/76/77/78)
22 12 SCREW–fuel bowl 18 2.0
23 3 PLUG KIT 22 2.5
24 3 SEAL–drain plug
2 MAIN FUEL JET (.052)(TOP)(WME–59)
1 MAIN FUEL JET (.054)(CENTER/BOTTOM)(WME–59)
3 MAIN FUEL JET (.054)(WME–60/61/76/77)
2 MAIN FUEL JET (.062)(TOP)(WME–62)
1 MAIN FUEL JET (.064)(CENTER/BOTTOM)(WME–62)
2 MAIN FUEL JET (.044)(Belgium) 14 1.6
1 MAIN FUEL JET (.052)(TOP)(WME–75)
2 MAIN FUEL JET (.054)(CENTER/BOTTOM)(WME–75)
1 MAIN FUEL JET (.062)(TOP)(WME–78)
2 MAIN FUEL JET (.064)(CENTER/BOTTOM)(WME–78)
