7B-6 -
A
TT
ACHMENTS/CONTROL LINKAGE
90-830234R3
DECEMBER 1997
Co-Pilot
1
2
3
4
5
6
7
8
7
8
REF
.
TORQUE
REF
.
NO.
QTY
.
DESCRIPTION
lb. in.
lb. ft.
N·m
–
1
CO-PILOT REPLACEMENT
ROD LENGTH
1
1
PILOT ROD
is 12-5/8 IN.
–
1
CO-PILOT REPLACEMENT
ROD LENGTH
1
1
PILOT ROD
is 14-5/8 IN.
2
1
NUT ASSEMBL
Y
3
1
SCREW
4
1
KNOB–PRONG
5
1
ROD
6
1
BUSHING
7
2
W
ASHER
8
2
NUT
T
ighten Until Nut
Seats; Do Not
Exceed 120 lb.
in.(13.6 N·m), then
back off 1/4 turn
