NOTE:
Fuel pressure values are approximate.
#1
CARB.
#2
CARB.
#3
CARB.
#4
CARB.
+4 .5 PSI
CYL. #3
CYL. #4
SMALL
FUEL
FIL
TER
ACCELERA
TOR
PUMP
FUEL
PRESSURE
DROP OCCURS
+3 .5 PSI
BRASS RESTRICTOR
(.014” I.D.) LOCA
TED
INSIDE FUEL LINE
CHECK V
AL
VES
LOCA
TED IN
CYLINDER BLOCK
TRANSFER PORTS
(UNSEA
T A
T 1
1–14 PSI)
LARGE
FUEL
FIL
TER
+5 .0 PSI
–0 .4 PSI
–0 .5 PSI
+5 .0 PSI
FUEL
PUMP
FUEL
T
ANK
+4.0 PSI
FUEL
CONNECTORS
90-830234R3 DECEMBER 1997
FUEL
SYSTEM - 3B-27
Acceleration Pump Fuel Flow Circuit for Four Cylinder Engines
188
190
