Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 FUEL SYSTEM - 3C-3
Oil Injection Components
(S/N–USA–0G301750/BEL–9885504 & BELOW)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 OIL TANK ASSEMBLY
2 1 COVER ASSEMBLY
3 1 GASKET
4 1 LATCH
5 1 SPRING
6 2 SCREW 35 4.0
7 2 WASHER
8 1 GROOVE PIN
8 1 ROLL PIN (.093 x 1.250)
9 1 VENT ASSEMBLY
10 1 VALVE
11 1 SCREW 50 5.6
12 1 WASHER
13 1 GROMMET
14 1 BUSHING
15 1 BOOT
16 1 BASE
17 2 SCREW 15 20.3
18 1 SWITCH ASSEMBLY
19 1 SCREW Drive Tight
20 1 WASHER
21 1 DRIVEN GEAR
22 2 O-RING
23 1 ADAPTOR ASSEMBLY
24 1 BUSHING
25 1 JOURNAL BUSHING
26 1 OIL PUMP
27 2 SCREW 60 6.8
28 1 TUBING (5-1/2 IN.)
29 1 TUBING (11 IN.)
30 AR STA-STRAP (8 IN.)
30 AR STA-STRAP (5-1/2 IN.)
