Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 FUEL SYSTEM - 3C-5
Oil Injection Components
(S/N–USA-0G301751/BEL–9885505 & UP)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 OIL TANK
2 1 CAP ASSEMBLY
3 1 O RING
4 1 DIPSTICK
5 1 NUT Push Nut
6 1 VENT ASSEMBLY
7 1 VALVE
8 1 BRACKET
9 1 BOOT
10 2 SCREW (M6X20) 65 7.5
11 1 GROMMET
12 1 BUSHING
13 1 WASHER
14 1 SCREW (M8X35) 15 20.5
15 1 SWITCH ASSEMBLY
16 1 SCREW Drive Tight
17 1 WASHER
18 1 DRIVEN GEAR
19 2 O-RING
20 1 ADAPTOR ASSEMBLY
21 1 BUSHING
22 1 JOURNAL BUSHING
23 1 OIL PUMP
24 2 SCREW 60 7.0
25 1 TUBING (5-1/2 IN.)
26 1 TUBING (11 IN.)
27
AR STA-STRAP (8 IN.)
27
AR STA-STRAP (5-1/2 IN.)
– 1 GASKET SET
