90-830234R3 DECEMBER 1997 POWERHEAD - 4-9

Cylinder Block (3 cyl.)

(USA-0G127499/BEL-9836632 & BELOW)

REF.

TORQUE

REF

NO.

QTY. DESCRIPTION lb. in. lb. ft. N·m

32 1 COVER ASSEMBLY

33 1 GASKET

34 1 PIPE PLUG

35 1 LIFTING EYE

36 1 THERMOSTAT

37 1 GASKET

38 1 GASKET

39 1 COVER

40 1 SCREW–air vent hole

41 5 SCREW (35 MM) 18 24.4

42 1 SCREW Drive Tight

43 1 WASHER

44 1 DIAPHRAGM

45 2 SCREW Drive Tight

46 1 WASHER

47 1 RETAINER

TEMPERATURE SENDER (ELECTRIC)

TEMPERATURE SENDER (MANUAL)

49 14 SCREW 18 24.4

50 4 CLAMP

51 1 BOOT

52 1 OIL WARNING MODULE

53 1

REV LIMITER (NON OIL INJECTION)

2 SCREW (M6 x 1 x 50) 80 9.0

2 SCREW (M6 x 1 x 30) 80 9.0

55 2 WASHER

56 1

HARNESS–speed limiter (NON OIL INJECTION)

57 1 HARNESS ADAPTOR
