90-830234R3 DECEMBER 1997 POWERHEAD - 4-19

Cylinder Block and Crankcase

(80 Jet/100/115/125)

REF.

TORQUE

REF

NO.

QTY. DESCRIPTION lb. in. lb. ft. N·m

CYLINDER BLOCK

USA-S/N-0G437999 /BEL-9926999 & BELOW

CYLINDER BLOCK

USA-S/N-0G438000 /BEL-9927000 & UP

2 10 SCREW (M10 x 80) 25 33.9

3 4 DOWEL PIN (BEARING RACE)

4 1 DOWEL PIN

5 1 COVER (TOP)

6 1 COVER (BOTTOM)

7 4 SCREW (M8 x 50) 12.5 16.9

8 1 CARRIER

9 1 GROMMET

10 1 CARRIER ASSEMBLY

11 3 CHECK VALVE

12 2 CHECK VALVE

13 8 STUD (M10)

14 8 WASHER

15 8 NUT 45 61

16 1 CHECK VALVE (PRESS-IN)

17 2 FITTING (S/N–USA–0G301750/BEL–9885504 & BELOW)

18 1 PLUG KIT

19 1 TUBING (S/N–USA–0G301750/BEL–9885504 & BELOW)

20 16 SCREW (8 x 35) 18 24.4

21 1 BOOT

22 1 COVER

23 1 GASKET

24 18 SCREW (M8 x 35) 18 24.4

25 5 CLAMP
