Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 POWERHEAD - 4-25
Throttle Lever and Linkage
(65 Jet/75/90 MODELS)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 THROTTLE LEVER
2 1 SCREW
3 1 CAP DESIGN II
4 1 SPRING
5 1 ADJUSTING SCREW DESIGN I
6 1 JAM NUT
7 1 SPARK ADVANCE LEVER
8 2 ADJUSTING SCREW (6 MM)
9 2 JAM NUT
10 2 NYLON CAP
11 1 BUSHING
12 1 SCREW Tighten Securely;
But Arm Must Pivot
Freely
13 1 WASHER
14 1 SPRING
15 1 PIN
16 1 WASHER
17 1 NUT Tighten Nut Secure-
ly; Then Back Off
Nut 1/4 Turn
18 1 SPARK ADVANCE ROD
19 2 SWIVEL BASE
20 2 SWIVEL BALL
21 1 THROTTLE ROD
22 1 SPRING
23 2 BUSHING
24 1 THROTTLE CAM
25 1 STUD
26 1 WASHER
27 1 NUT Drive Tight; But Joint
Must Be Free To
Pivot
