Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 POWERHEAD - 4-27
Throttle Lever (Models 80 Jet/100/115/125)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 THROTTLE LEVER
2 1 ADJUSTING SCREW
3 1
JAM NUT DESIGN I
4 1 NYLON CAP
5 1 SCREW (M5 x 40)
6 1 CAP DESIGN II
7 1 SPRING
8 1 NYLON CAP
9 1 SPARK ADVANCE LEVER
10 3 ADJUSTING SCREW (M6 x 55)
11 3 JAM NUT
12 3 NYLON CAP
13 1 SCREW (M10 x 45)
Tighten Screw Se-
curely; But Arm Must
Be Free To Pivot
14 1 BUSHING
15 1 SPRING
16 1 BUSHING
17 1 WASHER
18 1 PIN
19 1 WASHER
20 1 NUT
Tighten Nut Securely;
Then Back Off 1/4
Turn
21 1 SPARK ADVANCE ROD
22 1 SWIVEL BALL
23 1 SWIVEL BASE
24 1 LINK
25 1 NUT
Drive Tight; But Joint
Must be Free to
Pivot
26 2 BUSHING
27 1 THROTTLE CAM
28 1 STUD
29 1 WASHER
