Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 MID-SECTION - 5A-3
Swivel Bracket and Steering Arm (65 Jet/75/90)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 SWIVEL BRACKET (BLACK) NON-POWER TRIM
1
SWIVEL BRACKET (GRAY)
1
1 SWIVEL BRACKET (BLACK)
1
1 SWIVEL BRACKET (GRAY) MANUAL TILT ASSIST/POWER TRIM
1 SWIVEL BRACKET (TRACKER-GRAPHITE GRAY)
2 1 OIL SEAL(LOWER)
3 2 BUSHING
4 1 O-RING
5 1 SPACER
6 2 GREASE FITTING 40 4.5
7 2 BUSHING
8 2 SCREW(1/4-28 x 1/2) 100 11.3
9 1 STEERING LINK ASSEMBLY
10 1 SCREW(3/8 x 24 x 1-1/8) 20 27.0
11 2 NUT See Exploded View
12 2 WASHER
13 1 BUMPER--top yoke (X--LONG/LL)
1 SWIVEL PIN/STEERING ARM (BLACK)
14
1 SWIVEL PIN/STEERING ARM (GRAY)
1
4
1 SWIVEL PIN/STEERING ARM (TRACKER-GRAPHITE GRAY)
15 1 THRUST WASHER
1 SHOCK (BLACK) NO
1
6
1 SHOCK (GRAY) STAMPING
1
6
1 SHOCK (BLACK) STAMPED
1 SHOCK (GRAY) A12 or A17
17 1 GROOVE PIN
18 1 SHAFT(UPPER)
1 BOTTOM YOKE(BLACK)
19
1 BOTTOM YOKE (GRAY)
1
9
1 BOTTOM YOKE (TRACKER-GRAPHITE GRAY)
20 1 RETAINING RING
21 1 BRACKET
22 1 SHAFT(LOWER)
23 1 GROOVE PIN NON POWER TRIM
24 6 SCREW(M10 x 1.5 x 30) 30 40.7
2
5
6 WASHER
2
5
6 LOCKWASHER (JET)
26 1 ANODE ASSEMBLY
27 2 SCREW(M6 x 1 x 25) 60 6.8
28 2 WASHER
29 1 BUMPER--bottom yoke (X--LONG/LL)
