Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 MID-SECTION - 5A-5
Transom Bracket (Non Power Trim & Power Trim) (65 Jet/75/90)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1
TRANSOM BRACKET (STARBOARD)
2 1
TRANSOM BRACKET (PORT)
3 1
GREASE FITTING (PORT)
40 4.5
4 1
TILT PIN ASSEMBLY NON POWER TRIM
5 1 DECAL-tilt/lock
6 1 TILT TUBE
7 1 NUT
Tighten Nut until Bot-
tomed on Shoulder
of Tilt Tube
8 1 O-RING
9 2 WAVE WASHER
10 1 NUT
Drive Nut until As-
sembly is drawn to-
gether; but must be
free to pivot
11 4 BOLT (4-1/2 IN.)
12 4 WASHER
13 4 NUT
14 1 STOP
15 1
TILT LOCK LEVER (NON POWER TRIM)
16 1
TILT LOCK LEVER (POWER TRIM)
17 1 WAVE WASHER
18 2 BUSHING
19 1 KNOB
20 1 GROOVE PIN
21 1 SPRING
22 1 GROOVE PIN
23 1 BOLT ASSEMBLY
24 1 NUT 30 40.7
25 1 ANCHOR BRACKET
26 6 SCREW 45 61.0
27 6
WASHER POWER TRIM
28 1 NUT 45 61.0
