90-830234R3 DECEMBER 1997 MID-SECTION - 5A-9

Swivel Bracket and Steering Arm (80 Jet/100/115/125)

TORQUE

NO.

QTY. DESCRIPTION lb. in. lb. ft. N·m

1 SWIVEL BRACKET (BLACK)

1 SWIVEL BRACKET (GRAY)

1 SWIVEL BRACKET (TRACKER-GRAPHITE GRAY)

2 1 OIL SEAL (LOWER)

3 2 BUSHING

4 1 O-RING

5 1 SPACER

6 2 GREASE FITTING 40 4.5

7 2 BUSHING

8 2 SCREW 100 11.3

1 SWIVEL PIN/STEERING ARM (BLACK)

1 SWIVEL PIN/STEERING ARM (GRAY)

1 SWIVEL PIN/STEERING ARM (TRACKER-GRAPHITE GRAY)

10 1 STEERING LINK ASSEMBLY

11 1 SCREW 20 27.0

12 2 NUT See Exploded View

13 2 WASHER

14 1 BUMPER (X-LONG)

15 1 BUMPER (X-LONG)

1 BOTTOM YOKE (BLACK)

1 BOTTOM YOKE (GRAY)

1 BOTTOM YOKE (TRACKER-GRAPHITE GRAY)

17 1 RETAINING RING

18 1 THRUST WASHER
