Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 MID-SECTION - 5A-11
Transom Bracket
(S/N-USA-0G589999/BEL-9973099 & BELOW)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1
TRANSOM BRACKET (STARBOARD)
2 1
TRANSOM BRACKET (PORT)
3 1 GREASE FITTING (PORT)
4 1 TILT TUBE
5 1 NUT
Tighten Nut until Bot-
tom on Shoulder of
Tilt Tube
6 1 O-RING
7 2 WAVE WASHER
8 1 NUT
Drive Nut Until As-
sembly is Drawn to-
gether; But must free
to pivot
9 4 BOLT (4-1/2 IN.)
10 4 WASHER
11 4 NUT
12 1 STOP
13 1 TILT LOCK LEVER
14 1 WAVE WASHER
15 2 BUSHING
16 1 KNOB
17 1 GROOVE PIN
18 1 SPRING
19 1 GROOVE PIN
20 1 BOLT ASSEMBLY
21 1 NUT 30 40.7
22 1 ANCHOR BRACKET
23 6 SCREW 30 40.7
24 6 WASHER
25 1 NUT 30 40.7
26 1 ANODE
27 2 SCREW (M6 x 1 x 25)
28 2 WASHER
