90-830234R3 DECEMBER 1997 MID-SECTION - 5A-13
Transom Bracket
(S/N-USA-0G590000/BEL-9973100 & UP)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
29 1 TRANSOM BRACKET (STARBOARD) BLACK
30 1 TRANSOM BRACKET (PORT)
1 TRANSOM BRACKET (STARBOARD) GRAY
1 TRANSOM BRACKET (PORT)
31 1 GREASE FITTING (PORT) 40 4.5
32 1 TILT TUBE
33 1 NUT
Tighten Nut until Bot-
tomed on Shoulder of
Tilt Tube
34 1 O-RING
35 2 WAVE WASHER
36 1 NUT
Drive Nut until As-
sembly is drawn to-
gether; but must be
free to pivot
37 4 BOLT (4-1/2 IN.)
38 4 WASHER
39 4 NUT
40 1 SPRING
41 1 TILT LOCK LEVER
42 2 BUSHING
43 1 SPRING
44 1 KNOB
45 1 GROOVE PIN
46 1 PIN
4
7
1 ANCHOR BRACKET (BLACK)
4
7
1 ANCHOR BRACKET (GRAY)
48 6 SCREW 30 40.7
4
9
6 WASHER
4
9
6 LOCKWASHER (JET)
50 1 NUT 30 40.7
51 1 ANODE ASSEMBLY
52 2 SCREW (M6 x 25) 60 6.8
53 2 WASHER
