Mercury 90 - Page 310

90-830234R3 DECEMBER 1997 MID-SECTION - 5A-17
Exhaust Plate (80 Jet/100/115/125)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 EXHAUST PLATE ASSEMBLY
2 3 DOWEL PIN
3 2 SCREW (M8 x 35) 15 20.3
3 1 SCREW (M8 x 70) 15 20.3
4 1 MOUNT
5 4 SCREW 25 33.9
6 2 SCREW
7 2 WASHER
8 2 WASHER
9 2 NUT 55 74.6
10 1 GASKET
11 1 EXHAUST TUBE
12 6 SCREW 25 33.9
13 1 SEAL--exhaust tube
14 1 GROMMET
1
5
1
WATER TUBE (LONG)
1
5
1
WATER TUBE (X-LONG)
16 1 CLAMP
17 1 SEAL (UPPER)
18 2 SCREW (M8 x 50) 15 20.3
19 1
BRACKET ASSEMBLY (LOWER) (BLACK)
20 1 SEAL
21 1
GROMMET (S/#-0G359967 & BELOW)
22 1
GROMMET (S/#--0G359968 & UP)
23 3 SCREW (M8 x 50) 25 33.9
24 1 BUSHING
25 1 SHIFT SHAFT ASSEMBLY (UPPER)
26 1 SHIFT LINK
27 2 BUSHING
28 1 NUT
Drive Tight; but Joint
must be free to Pivot
2
9
1
SPACER (LONG)
2
9
1
SPACER (X-LONG)
30 1 COUPLING
