Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 MID-SECTION - 5A-19
Drive Shaft Housing (65 Jet/75/90)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 DRIVE SHAFT HOUSING ASSEMBLY
2 1 STUD (100MM)(LONG)
2 1 STUD (166MM)(LL)
3 4 SCREW (M10 x 1.5 x 45)(LONG)(DESIGN I) 40 54.2
4 4 STUD (63MM)(LONG)(DESIGN II)
4 4 STUD (124M)(LL)
5 5 WASHER
6 AR NUT 40 54.2
7 1 GUIDE (NON POWER TRIM)
8 1 SPEEDOMETER PICK-UP ASSEMBLY
9 1 CONNECTOR (90°)
10 1 CONNECTOR (STRAIGHT)
11 1 REVERSE HOOK ASSEMBLY
12 1 PUSH ROD
13 1 SHAFT
14 1 COTTER PIN
15 2 BUSHING
16 1 SPRING
17 1 COTTER PIN NON
18 1 WASHER POWER TRIM
19 1 SPRING
20 1 YOKE
21 1 JAM NUT
22 1 CLEVIS PIN
23 1 COTTER PIN
24 2 MOUNT (ELO/ELHPTO/SCATTO/TYPHOON)
24 2 MOUNT (ALL OTHER MODELS)
25 2 BOLT (M12 x 1.75 x 154)
26 2 COVER (BLACK)
27 4 SCREW (12-24 x 5/8²) Drive Tight
28 2 WASHER
29 2 NUT 50 67.8
30 2 GROUND WIRE ASSEMBLY
31 1 SCREW (1/4-20 x 1/2) Drive Tight
32 2 CLAMP
33 4 NUT
34 4 SCREW (M8 x 1.25 x 25) 13.5 18.3
35 1 SPACER (2-1/2²)
35 1 SPACER (5²)
36 1 DOWEL PIN X-LONG
36 1 DOWEL PIN (W/HOLE)
37 4 NUT 40 54.2
38 4 STUD (124MM)(2-1/2² SPACER)
38 4 STUD (190MM)(5² SPACER)
39 1 STUD (166MM)(2-1/2² SPACER)
39 1 STUD (227MM)(5² SPACER)
