90-830234R3 DECEMBER 1997 MID-SECTION - 5A-21
Drive Shaft Housing (80 Jet/100/115/125)
TORQUE
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 DRIVE SHAFT HOUSING ASSEMBLY
1
DRIVE SHAFT HOUSING ASSEMBLY (JET)
1
STUD (LONG)
1
STUD (X-LONG)
3 2 DOWEL PIN
4
STUD (LONG)
4
STUD (X-LONG)
5 5 WASHER
6 5 NUT 40 54.2
1
SPACER--drive shaft housing X-LONG
1 SPACER--drive shaft housing
1 DOWEL PIN (W/HOLE)
DOWEL PIN
9 1 SPEEDOMETER PICK-UP ASSEMBLY
10 1 CONNECTOR (90 Degrees)
11 1 CONNECTOR (STRAIGHT)
12 2 MOUNT
13 2 BOLT
14 2 WASHER
15 2 NUT 50 67.8
16 2 GROUND WIRE ASSEMBLY
17 1 SCREW Drive Tight
18 2 CLAMP
19 4 NUT
20 4 SCREW (M8 x 25) 13.5 18.3
21 2 COVER
22 4 SCREW Drive Tight
To Next Page
