Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 MID-SECTION - 5B-3
Power Trim Components (Black Fill Plug)
(S/N-USA-0G360002/BEL-9934136 & BELOW)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
– 1 POWER TRIM PUMP
1 1 SHOCK ROD ASSEMBLY
2 1 CYLINDER END CAP
3 1 CYLINDER SEAL KIT
4 1 MEMORY PISTON KIT
5 1 CYLINDER
6 1 SCREW AND SEAL KIT 100 11.3
7 1 PUMP/MANIFOLD
8 1 ROCKER ARM 130 14.7
9 1 SCREW KIT 70 7.9
10 1 DRIVE SHAFT
11 1 SEAL KIT(W/CASE BOLTS) 13 1.5
12 1 RESERVOIR
13 1 PLUG KIT Drive Tight
14 1 RELIEF VALVE KIT
15 1 FRAME AND FIELD KIT 13 1.5
16 1 ARMATURE KIT
17 1 BRUSH SPRING KIT
18 1 BRUSH CARD KIT
19 1 ANCHOR PIN
20 2 GROOVE PIN
21 1 SHAFT
22 1 TRIM HARNESS ASSEMBLY
23 2 SCREW Drive Tight
24 2 C-WASHER
25 2 CLAMP
26 2 SOLENOID
27 4 BUSHING
28 4 GROMMET
29 4 SCREW 35 4.0
30 4 WASHER
31 4 NUT(8-32 Brass) 20 2.3
32 4 LOCKWASHER
33 4 NUT(1/4 - 20) 50 5.6
34
2 CABLE (RED – 2-3/4 IN.)(USE WHERE APPLICABLE)
34
AR CABLE (BLACK – 3-1/2 IN.)
