90-830234R3 DECEMBER 1997 MID-SECTION - 5C-5
Description
The Power Trim system consists of an electric motor,
pressurized fluid reservoir, pump and trim cylinder.
The remote control (or trim panel) is equipped with a
switch that is used for trimming the outboard “up” and
“down”, and for tilting the outboard for shallow water
operation (at slow speed) or for “trailering”. The out-
board can be trimmed “up” or “down” while engine is
under power or when engine is not running.
