5C-24 - MID-SECTION
90-830234R3
DECEMBER 1997
Hydraulic System T
roubleshooting Flow Chart
Replace trim system
continued
Replace suction seat
assembly
Remove suction seat as-
sembly and inspect for
debris and/or damage
Debris and/or damage
identified
T
rim system holds
reverse thrust:
T
esting complete
T
rim will not hold
reverse thrust
Suction seat assembly
appears O.K. - Clean and
reinstall suction seat as-
sembly
T
rim system holds
reverse thrust:
T
esting complete
383
385
