Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 ELECTRICAL - 2A-7
3 Cylinder Electrical Components
(USA-S/N-0G438000/BEL-9937000 & UP)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1
1 IGNITION PLATE
2
3 SCREW(M8 x 30)
3
3 WASHER
4
3 BUSHING
5
3 GROMMET
6
4 SCREW(M5 x 12) ELECTRIC
7
1
CLAMP
8
1 CABLE(10 IN.)
9
2 SCREW(M5 x 12)
10
2 WASHER
11
1 HARNESS-Engine
12
1 FUSE ELECTRIC
13
1 HARNESS-Ignition
14
1 BATTERY CABLE (POSITIVE)
15
1 BOOT
16
3 CDM
17
3 HI–TENSION CABLE
18
3 BOOT
19
3 SPARK PLUG(NGK #BUHW-2) 20
27
19
3 SPARK PLUG(BELGIUM/CANADA)(NGK#BUZHW) 20
27
20
6 SCREW(M6 x 16)
21
1 STARTER SOLENOID
22
2 BUSHING
23
2 GROMMET
24
2 NUT(8-32) ELECTRIC
25
1 CABLE
26
2 LOCKWASHER(5/16 IN.)
27
2 NUT(5/16-8)
28
2 SCREW(M6 x 25)
29
1 VOLTAGE REGULATOR
30
1 STA–STRAP
31
2 SCREW(M6 x 35)
32
1 J CLIP
33
1 CABLE
34
2 CLAMP
35
1 HARNESS-Engine (MANUAL)
36
1 WASHER
