GASOLINE ENGINES BRAVO MODELS
Page 28 of 116
CAUTION
Avoid engine overheating which could result in engine damage. On models
equipped with Closed Cooling, an air pocket may form in the closed cooling system
if some coolant is lost from the system and the cabin heater or hot water is mounted
higher than the fill cap on the heat exchanger. Heater must be mounted lower
than
the fill cap of the heat exchanger on models so equipped.
SUPPLY HOSE CONNECTION
75473
a
74973
Seawater Cooling - If Location Is Available
a-Location For Hot Water Supply
71758
a
Seawater Cooling - Alternate Location
a-Location For Hot Water Supply (Install Bayonet Fitting Here)
74639
a
a
b
b
Closed Cooling Models - If Location Is Available
a-Location for Hot Water Supply (Bayonet Fitting Replaces Brass Plug)
b-Thermostat Housing
