GASOLINE ENGINES BRAVO MODELS
Page 62 of 116
Quick Drain Oil Installation (If Equipped)
1. Install flange over cable.
2. Fasten flange to hull with appropriate fasteners (not provided).
3. Install bilge drain plug in hull.
a
b
c
d
e
76882
a-Bilge Drain Plug
b-Tether
c-Quick Oil Drain Hose Plug
d-Flange
e-Toward Interior Of Boat
4. Install quick oil drain hose plug in oil drain hose.
IMPORTANT: If Quick Drain Oil Fitting is within 1/2 in. (6 mm) of boat bottom, remove
fitting and install drain plug from parts bag directly into oil pan.
