Mercury BRAVO User Manual

GASOLINE ENGINES BRAVO MODELS
Page 88 of 116
2. Install propeller with attaching hardware as shown. Tighten nut a minimum of 55lb-ft
(75 Nm), then continue to tighten until 3 tabs on the tab washer align with grooves
on spline washer. Bend the 3 tabs down into grooves.
76910
a
b
c
f
e
g
d
Bravo One
a-Apply Lubricant on Splines of Propeller Shaft
b-Forward Thrust Hub
c-Flo-Torque Drive Hub
d-Propeller
e-Drive Sleeve Adapter
f-Tab Washer
g-Locknut
70561
a
b
c
d
e
f
Bravo Two
a-Apply Lubricant on Splines of Propeller Shaft
b-Forward Thrust Hub
c-Propeller
d-Continuity/Spline Washer
e-Tab Washer
f-Locknut
