AC1200 Wireless Dual Band Gigabit Router
• Renew - Click to renew the IP parameters from your ISP.
• Release - Click to release the IP parameters.
• MTU Size - The normal MTU (Maximum Transmission Unit) value for most Ethernet
networks is 1500 bytes. Do not change the default MTU Size unless required by your ISP.
• Manually set DNS server - If your ISP gives you one or two DNS addresses, select this
option and enter the primary and secondary addresses into the corresponding fields.
Otherwise, the DNS servers will be assigned dynamically from your ISP.
• Host Name - This option specifies the host name of the router.
• Get IP with Unicast DHCP - A few ISPs' DHCP servers do not support the broadcast
applications. If you cannot get the IP Address normally, you can choose this option. (It is
rarely required.)
Click Save to make the settings effective.
3. Static IP
Select this type if your ISP provides a static IP address, subnet mask, gateway and DNS
- 19 -
