Mercusys MW305R User Manual

MW305R
300Mbps Wireless N Router User Guide
 End IP Address - Specify an IP address for the DHCP Server to end with when assigning IP
addresses. 192.168.1.199 is the default end address.
 Address Lease Time - The amount of time a network user will be allowed connection to the
router with their current dynamic IP Address. Enter the amount of time in minutes and the
user will be leased this dynamic IP Address. After the time is up, the user will be
automatically assigned a new dynamic IP address. The range of the time is 1 ~ 2880
minutes. The default value is 120 minutes.
 Gateway - (Optional.) It is recommended to enter the IP address of the LAN port of the
router. The default value is 192.168.1.1.
 Primary DNS - (Optional.) Enter the DNS IP address provided by your ISP or consult your
ISP.
 Secondary DNS - (Optional.) Enter the IP address of another DNS server if your ISP
provides two DNS servers.
 Host - The name of the DHCP client.
 MAC Address - The MAC address of the DHCP client
 IP Address - The IP address that the router has allocated to the DHCP client
 Effective Time - The time of the DHCP client leased. After the dynamic IP address has
expired, a new dynamic IP address will be automatically assigned to the user.
Click Refresh to show the current attached devices.
NOTE:
To use the DHCP server function of the router, you must configu
re all computers on the LAN as
Obtain an IP Address automatically.
- 25 -

Mercusys MW305R Specifications

General

DSL WAN	-
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Product type	Tabletop router
Product color	White
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	5 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Transmit power	0 dBmW
Antenna gain level (max)	5 dBi
Certification	CE RoHS
Cables included	LAN (RJ-45)
Supported network protocols	IPv4
Security algorithms	WPA-PSK, WPA2-PSK
Package type	Box
Package depth	198 mm
Package width	267 mm
Package height	68 mm
Package weight	450 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	115.44 mm
Width	168.94 mm
Height	34.66 mm
