Mercusys MW305R User Manual

MW305R
300Mbps Wireless N Router User Guide
5.3 Network Control
There are two submenus under the Network Control menu: Parental Controls and Access
Control. Click any of them to configure the corresponding function.
5.3.1 Parental Controls
Go to Network Control
→
Parental Controls, and then you can configure the parental controls in
the screen. The Parental Controls function can be used to control the internet activities of the child,
limit the child to access certain websites and restrict the time of surfing.
 Parental Controls – Click to enable or disable this function.
 Parental Devices – Displays the MAC address of the controlling PC.
 Edit - Here you can edit an existing entry.
 Add - Click to add a new device.
 Delete All - Click to delete all devices in the table.
 Delete Selected - Click to delete selected devices from the table.
 Effective Time - All devices except the parental devices will be restricted. Click and drag
across the cells to set the restriction time periods.
- 31 -

Mercusys MW305R Specifications

General

DSL WAN	-
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Product type	Tabletop router
Product color	White
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	5 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Transmit power	0 dBmW
Antenna gain level (max)	5 dBi
Certification	CE RoHS
Cables included	LAN (RJ-45)
Supported network protocols	IPv4
Security algorithms	WPA-PSK, WPA2-PSK
Package type	Box
Package depth	198 mm
Package width	267 mm
Package height	68 mm
Package weight	450 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	115.44 mm
Width	168.94 mm
Height	34.66 mm
