Mercusys MW305R User Manual

MW305R
300Mbps Wireless N Router User Guide
not accept it as the MAC address is changed. In this case, you need to clone your computer’s
MAC address to the router.
 Manually set MAC address - If your ISP requires you to register the MAC address, please
enter the correct MAC address into this field in XX-XX-XX-XX-XX-XX format (X is any
hexadecimal digit).
Click Save to make the settings effective.
5.1.5 DHCP Server
Go to Network→DHCP Server, you can configure the DHCP Server settings on the page. The
router is set up by default as a DHCP (Dynamic Host Configuration Protocol) server, which
provides the TCP/IP configuration for all the PCs that are connected to the router on the LAN.
 DHCP Server - Click the button to enable or disable the DHCP server. If you disable the
server, you must have another DHCP server within your network or else you must configure
the computer manually.
 Start IP Address - Specify an IP address for the DHCP Server to start with when assigning
IP addresses. 192.168.1.100 is the default start address.
NOTE:
Only the PC on your LAN can use the MAC Clone function.
- 24 -

Mercusys MW305R Specifications

General

DSL WAN	-
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Product type	Tabletop router
Product color	White
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	5 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Transmit power	0 dBmW
Antenna gain level (max)	5 dBi
Certification	CE RoHS
Cables included	LAN (RJ-45)
Supported network protocols	IPv4
Security algorithms	WPA-PSK, WPA2-PSK
Package type	Box
Package depth	198 mm
Package width	267 mm
Package height	68 mm
Package weight	450 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	115.44 mm
Width	168.94 mm
Height	34.66 mm
