Mercusys MW305R User Manual

MW305R
300Mbps Wireless N Router User Guide
 Ping Timeout - Time to wait for a response, in milliseconds. The default is 800.
 Tracert Max Hops - Set the maximum number of hops (max TTL to be reached) in the path to
search for the target (destination). The default is 20.
Click Start to check the connectivity of the Internet.
The Diagnostic Results page displays the result of diagnosis.
5.5.9 System Log
Go to System Tools
→
System Log, and then you can view the logs of the router.
 Refresh - Refresh the page to show the latest log list.
 Save Log - Click to save all the logs in a txt file.
 Clear All Logs - All the logs will be deleted from the router permanently, not just from the
page.
NOTE:
1. Only one user can use the diagnostic tools at one time.
2.
Ping Packet Number, Ping Packet Size and Ping Timeout are Ping Parameters, and
Tracert Max Hop is Tracert Parameter.
- 48 -

Mercusys MW305R Specifications

General

DSL WAN	-
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Product type	Tabletop router
Product color	White
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	5 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Transmit power	0 dBmW
Antenna gain level (max)	5 dBi
Certification	CE RoHS
Cables included	LAN (RJ-45)
Supported network protocols	IPv4
Security algorithms	WPA-PSK, WPA2-PSK
Package type	Box
Package depth	198 mm
Package width	267 mm
Package height	68 mm
Package weight	450 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	115.44 mm
Width	168.94 mm
Height	34.66 mm
