Mercusys MW305R User Manual

MW305R
300Mbps Wireless N Router User Guide
 Ping - This diagnostic tool troubleshoots connectivity, reachability, and name resolution to a
given host or gateway.
 Tracert - This diagnostic tool tests the performance of a connection.
 IP Address/Domain Name - Enter the IP address or domain name of the PC whose
connection you wish to diagnose.
 Pings Packet Number - Specifies the number of Echo Request messages sent. The default
is 4.
 Ping Packet Size - Specifies the number of data bytes to be sent. The default is 64.
NOTE:
Y
ou can use ping/tracert to test numeric IP address or domain name. If pinging/tracerting the IP
address is successful, but pinging/tracerouting the domain name is not, you might have a name
resolution problem. In this case, ensure that the specified domain name
can be resolved by
using Domain Name System (DNS) queries.
- 47 -

Mercusys MW305R Specifications

General

DSL WAN	-
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Product type	Tabletop router
Product color	White
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	5 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Transmit power	0 dBmW
Antenna gain level (max)	5 dBi
Certification	CE RoHS
Cables included	LAN (RJ-45)
Supported network protocols	IPv4
Security algorithms	WPA-PSK, WPA2-PSK
Package type	Box
Package depth	198 mm
Package width	267 mm
Package height	68 mm
Package weight	450 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	115.44 mm
Width	168.94 mm
Height	34.66 mm
