Mercusys MW305R User Manual

MW305R
300Mbps Wireless N Router User Guide
 Website Domain - Here you can enter 4 domain names, either the full name or the
keywords (for example, Mercusys). Any domain name with keywords in it
(www.mercusys.com) will be blocked or allowed.
6. Click Configure in the Schedule column, you can select Any Time, or select Add to add a
new schedule. Then click Apply.
 Description - In this field, create a description for the schedule. Note that this
description should be unique.
 Time - Click and drag across the cells to set the effective time periods.
7. Click Save to complete the settings.
5.4 Advanced Users
There are five submenus under the Forwarding menu: Virtual Server, DMZ Server, UPnP
- 35 -

Mercusys MW305R Specifications

General

DSL WAN	-
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Product type	Tabletop router
Product color	White
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	5 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Transmit power	0 dBmW
Antenna gain level (max)	5 dBi
Certification	CE RoHS
Cables included	LAN (RJ-45)
Supported network protocols	IPv4
Security algorithms	WPA-PSK, WPA2-PSK
Package type	Box
Package depth	198 mm
Package width	267 mm
Package height	68 mm
Package weight	450 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	115.44 mm
Width	168.94 mm
Height	34.66 mm
