Mercusys MW305R User Manual

MW305R
300Mbps Wireless N Router User Guide
Click Backup to save all configuration settings as a backup file to your local computer.
To upgrade the router's configuration, follow the steps below.
1. Click Browse to locate and select the configuration file which you want to restore.
2. Click Restore to update the configuration with the file you have selected.
5.5.6 Reboot
Go to System Tools
→
Reboot, and then you can click the Reboot button to reboot the router on
the page.
NOTE:
1. All current configurations will be lost once the router is restored.
2. To avoid any damage, keep the device powered on during the process
3.
After the upgrade process is complete (about 20 seconds), the device will reboot
automatically.
- 45 -

Mercusys MW305R Specifications

General

DSL WAN	-
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Product type	Tabletop router
Product color	White
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	5 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Transmit power	0 dBmW
Antenna gain level (max)	5 dBi
Certification	CE RoHS
Cables included	LAN (RJ-45)
Supported network protocols	IPv4
Security algorithms	WPA-PSK, WPA2-PSK
Package type	Box
Package depth	198 mm
Package width	267 mm
Package height	68 mm
Package weight	450 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	115.44 mm
Width	168.94 mm
Height	34.66 mm
