Installation
The plug and cord on the trolley will be of a type and rating that meet the required electrical voltage and current requirements
of the trolley. The measured supply voltage must be within 10% of the name plate rating. Check the rating plate on each piece
of equipment for further details. If the power supply available does not suit the electrical requirements of the trolley, contact
our Service Department or an Authorised Service Agent.
Check that the wall socket or cord set has been installed by a qualified electrician and is correctly connected to Earth. Ensure
the power supply is compatible to that which is stated on the rating plate. Ideally, the trolley should be connected to a switched
socket incorporating both an earth fault device and over current protection.
Ensure the socket or cord set is located so that the trolley cannot damage it, yet remains easily accessible to the operator
without stressing the power cable.
The electrical installation must conform to the national and local Electrical Codes.
The transportation route and access should be checked for any obstructions that may cause damage to the trolley.
• Check the electrical compartment of the unit for a sachet of desiccant silica crystals. If has been included please
remove it and dispose it in compliance with the local laws and regulations.
Plug Connections Multigen 208v 60Hz 3P+N+E
NOTE. If your trolley is supplied without a plug on the power supply cable or the plug must be replaced, ensure that the plug is
an exact NEMA replacement (L21-30P) and that it corresponds with the trolley data plate. The conductors must be connected
to conform to the table below.
Three Phase, Neutral and Earth
PLUG
SUPPLY
Phase X : Orange
Phase Y : Black
Phase Z : Red
Neutral N: White
Earth G: Green
Extended Cables 208v 60Hz 3P+N+E
:
Always avoid long cables. It is much safer to reposition the socket to a more appropriate location.
