Metos Multigen - 58. Installation Continued; Plug Connections and Cable Usage (400 V)

12.09.05 rev 1.0
53
59.
Electrical Specification
60 Hertz Versions
ELECTRICAL SPECIFICATION
208v 60Hz 3P+N+E 120v 60Hz 1P+N+G
DESCRIPTION REFERENCE
GRID
CAPACITY
AMPS KW AMPS KW
Multigen I M21.100 8 15.5 5.4 14.3 1.7
Multigen II M22.100 8 15.5 5.4 14.3 1.7
Minigen M20.100 8 15.5 5.4 14.3 1.7
50 Hertz Versions
ELECTRICAL SPECIFICATION
400V 50Hz 3P+N+E 230V 50Hz 1P+N+E
DESCRIPTION REFERENCE
GRID
CAPACITY
AMPS KW AMPS KW
Multigen I M21.100 8 N/A N/A 12 2.8
Multigen I M21.300 8 12 7.8 N/A N/A
Multigen II M22.100 8 N/A N/A 12 2.8
Multigen II M22.300 8 12 7.8 N/A N/A
Minigen M20.100 8 N/A N/A 12 2.8
Minigen M20.300 8 12 7.8 N/A N/A
Optional Features
ELECTRICAL SPECIFICATION
50Hz VERSIONS 60Hz VERSIONS
OPTIONAL FEATURES MODEL
KW KW
Heated Top Plate Multigen 0.5 0.4
Heated Top Plate Minigen 0.25 0.2
Infra-red Gantry Element Multigen 1.0 0.8
Infra-red Gantry Element Minigen 0.5 0.4
Plate Warmer Multigen 0.2 0.2
Refrigerated Section Multigen 0.6 0.6
Cold Display Light Multigen 0.03 0.05
Cold Display Light Minigen 0.03 0.05
