MI 3290 Earth Analyser Appendix E – Programming of Auto Sequences®…
152
Appendix E – Programming of Auto Sequences®
on Metrel ES Manager
The Auto Sequence® Editor is a part of the Metrel ES Manager software. In Auto Sequence®
Editor an Auto Sequence® can be pre-programmed and organized in groups, before uploaded to
the instrument.
I. Auto Sequence® Editor workspace
To enter Auto Sequence® Editor’s workspace, select in Home Tab of Metrel ES
Manager PC SW. Auto Sequence® Editor workspace is divided in four main areas. On the left
side ,structure of selected group of Auto Sequence® is displayed. In the middle part of the
workspace , the elements of the selected Auto Sequence® are shown. On the right side, list
of available single tests and list of flow commands are shown.
Figure E.1: Auto Sequence® Editor workspace
An Auto Sequence® begins with Name, Description and Image, followed by the first step
(Header), one or more measuring steps and ends with the last step (Result). By inserting
appropriate Single tests and Flow commands and setting their parameters, arbitrary
Auto Sequences® can be created.
