MI 3290 Earth Analyser Memory Organizer
45
or
at least one single test in the Auto
Sequence® was carried out and there were
no other passed or failed single tests.
or
empty Auto Sequence® with empty single
tests
9.1.2 Structure items
Each Structure item has:
 an icon
 a name and
 parameters.
Optionally they can have:
 an indication of the status of the measurements under the Structure and a comment or a
file attached.
Figure 9.2: Structure project in tree menu
9.1.3 Measurement status indication under the Structure item
Overall status of measurements under each structure item /sub-item can be seen without
spreading tree menu. This feature is useful for quick evaluation of test status and as guidance for
measurements.
Options
There are no measurement results under
selected structure item.
Measurements should be made.
One or more measurement result(s)
under selected structure item has failed.
Not all measurements under selected
structure item have been made yet.
All measurements under selected
structure item are completed but one or
more measurement result(s) has failed.
